CS1732B / CS1734B User Manual
28
OSD Navigation
To select a port, use the F1, F2, F3 and F7 Keys then click on the Up and
Down Arrow Keys to move the Highlight Bar down the list on the screen.
When the Highlight Bar is on the port you want to switch to, press [Enter]
or double click the left button of the mouse. The Pointing Finger icon will
appear on the port selected, the OSD will disappear and the screen of the
selected port will be displayed.
The KVM, USB, Audio, and PN columns can also be selected with the
mouse. Using the mouse allows you to select single or multiple columns.
Double clicking with the mouse or pressing [Enter] will activate the
Highlight Bar. The Pointing Finger icon will appear on the port selected,
the OSD will disappear and the screen of the selected port will be
displayed.
The KVM, USB, Audio, and PN columns can also be selected by pressing
the Tab key. Use the Up and Down Arrow Keys to select the port number
then press [Enter]. Alternatively, double click on the Highlight Bar. The
Pointing Finger icon will appear on the port selected, the OSD will
disappear and the screen of the selected port will be displayed.
In the Name column, use the Up and Down Arrow keys to select a port.
Once a port has been selected, you can edit its name after double clicking
with the mouse or pressing [Enter].
In all of the port selection methods outlined above, pressing [F7] or using
the mouse to select a port number in the Name column will switch the
KVM, USB and Audio focus on the selected port simultaneously.
To exit the Main Screen/Port Display, press [Esc] or click the right button
of the mouse. The OSD will disappear and the original computer screen
will be displayed. Settings will not be stored on exit.
To store settings on exit, press [Enter] or move to the cursor to the central
yellow area or the Highlight Bar and double click with the left button of
the mouse. Then exit as outlined above.
