CS1732B / CS1734B User Manual
26
Hotkey Summary Table
[Num Lock] + [-] [Enter] Brings the KVM, USB hub, and audio focus from
the port that currently has the KVM focus to the
next port on the installation.
[Port ID]
[Enter]
Switches access to the computer that corresponds
to that Port ID.
[K] or [U] or
[S] [Enter]
Brings only the KVM or USB hub or audio focus
from the port that currently has it to the next port
on the installation.
[Port ID] [K] or
[U] or [S]
Brings the KVM or USB hub or audio focus to the
computer attached to the corresponding port.
[A] [n] Sets the Auto Scan interval to n seconds – where
n is a number from 1–255.
[A] Invokes Auto Scan Mode.
[←] Invokes Skip Mode and Skips from the current port
to the first accessible port previous to it.
[→] Invokes Skip Mode and Skips from the current port
to the next accessible port.
[↑] Invokes Skip Mode and Skips from the current port
to the last accessible port of the previous Station.
[↓] Invokes Skip Mode and Skips from the current port
to the first accessible port of the next Station.
[D] Invokes Video DynaSync so the CS1732
B /
CS1734
B stores the console monitor’s EDID.
[F4] Lists the current OSD settings via the Paste
function of a text editor, including
a) Hotkey
b) OSD Hotkey
c) Port OS
d) Mouse Emulation
e) Button Settings
[F5] Performs USB Keyboard and Mouse reset.
[H] Toggles between the default and alternate HSM
invocation keys.
[T] Toggles between the default and alternate OSD
Invocation keys.
