ATEN CS1732B User Manual

Appendix
45
Specifications
Function CS1732B CS1734B
Computer Connections 2 4
Port Selection OSD; Hotkeys; Pushbuttons
Connectors Console
Ports
KB 1 x USB Type A F (Black)
Video 1 x HDB-15 F (Blue)
Mouse 1 x USB Type A F (Black)
Speaker 2 x Mini Stereo Jack F (Green)
Mic. 2 x Mini Stereo Jack F (Pink)
KVM Ports KB
2 x SPHD-15 F
(Yellow)
4 x SPHD-15 F
(Yellow)
Video
Mouse
Speaker 2 x Mini Stereo Jack F
(Green)
4 x Mini Stereo Jack F
(Green)
Mic. 2 x Mini Stereo Jack F
(Pink)
4 x Mini Stereo Jack F
(Pink)
F/W Upgrade 1 x 4-conductor 3.5 mm Jack (Black)
Power 1 x DC Jack (Black)
USB Hub 2 x USB Type A F (White; 1 x front panel, 1 x
rear panel)
Switches Selected 2 x Pushbutton 4 x Pushbutton
LEDs On Line / Selected 2 (Orange) 4 (Orange)
USB Link 2 (Green) 4 (Green)
Emulation Keyboard / Mouse PS/2; USB
Video 2048 x 1536 @ 60Hz; DDC2B
Scan Interval 1–255 seconds (Default: 5; Disabled: 0)
Power Consumption DC5.3V/3.1W (max.) DC5.3V/3.4W (max.)
Environment Operating Temp.
0–50
o
C
Storage Temp.
-20–60
o
C
Humidity 0–80% RH, Non-condensing
Physical
Properties
Housing Metal
Weight 0.55 kg 0.78 kg
Dimensions 14.00 x 8.70 x 5.50 cm 21.00 x 8.70 x 5.50 cm
