Operator's instructions

4. Controls

5 Lubrication air manometer

6 Air plant pressure manometer

7 General gear pump pressure manometer

8 LS pump pressure manometer

Gradient meter

Figure: Gradient meter

The meter indicates the angles for safe operation of the drill rig. The chassis could tip

over outside the specified angle limits.

• The gradient meter shows the chassis

frame angle and not the actual ground

camber
