‘Clock Function’
‘Not activated’
.
‘Menu’ ‘Mod.’ ‘Del’
F1 F2 F3
• Press the tabulator key (2), the following screen appears:
‘Monday’
‘Tuesday’
‘Wednesday’
‘Menu’ ‘Del’
F1 F2 F3
• Scroll through the display until ‘Saturday’ is followed by a horizontal arrow. Press the
tabulator key (2). If necessary, scroll through the commands until the command to be
modified is followed by a horizontal arrow. Press the key ‘Mod.’, the first two digits of the
command start flashing. Modify as required using the scroll keys, i.e. in the example above
change 18 into 17 using the arrow up key (1).
• If necessary, press the tabulator key (2) to go to the next field to be modified, the minutes
indication and the start/stop/pressure band indication.
• Press the key ‘Prog’ to program the new command or the key ‘Canc’ to quit without
reprogramming.
Adding a command at the end of an existing list
• Starting from the Main screen, press the key ‘Menu’ (F1), press the arrow down key until the
option ‘Modify Params’ is followed by a horizontal arrow.
• Activate the menu by pressing the tabulator key (2).
• Use the arrow down key (1) to scroll until the option ‘Clock Function’ is followed by a
horizontal arrow. Press the tabulator key, the following screen appears:
‘Clock Function’
‘Not activated’
.
‘Menu’ ‘Mod.’ ‘Del’
F1 F2 F3
Suppose the command to stop the compressor at 18:00 must be added to the list of Monday.
• Press the tabulator key (2); the following screen appears:
‘Monday’
‘Tuesday’
‘Wednesday’
‘Menu’ ‘Del’
F1 F2 F3
Instruction book
36 API161475
