• Scroll through the display until ‘Monday’ is followed by a horizontal arrow. Press the
tabulator key (2). Scroll through the compressor start/stop/pressure band commands until
the first empty command line is indicated by the horizontal arrow.
• Press the key ‘Mod.’; the first two digits start flashing. Enter 18:00 ‘Comp’ ‘Stop’ using the
scroll keys (1) to modify a field and the tabulator key (2) to jump from one field to another.
• Press the key ‘Prog’ to program the new command or the key ‘Canc’ to quit without
reprogramming.
Adding a command between two existing commands
Suppose the command 17:00 ‘Press Band 2’ must be added to the following list:
• 06:00 ‘Start’ ‘Comp’
• 06:00 ‘Press Band 1’
• 18:00 ‘Stop’ ‘Comp’
The regulator does not allow the entering of a new command which time-wise is situated before
the last command in the list.
Scroll through the display until the command before which the new command must be entered is
followed by a horizontal arrow (in the example above: 18:00 ‘Stop’ ‘Comp’) and press the key
‘Mod.’.
Change this command to the new command (in the example above 17:00 ‘Press Band 2’)
Press the arrow down key and add the last command of the list (in the example above 18:00
‘Stop’ ‘Comp’ and press the key ‘Prog’.
Deleting a command
• Starting from the Main screen, press the key Menu (F1), press the arrow down key until the
option ‘Modify Params’ is followed by a horizontal arrow.
• Activate the menu by pressing the tabulator key (2).
• Use the scroll keys (1) to scroll until the option ‘Clock Function’ is followed by a horizontal
arrow. Press the tabulator key; the following screen appears:
‘Clock Function’
‘Not activated’
.
‘Menu’ ‘Mod.’ ‘Del’
F1 F2 F3
Deleting all commands
• Press the key ‘Del’ in the screen above. A question to confirm the deleting operation will
appear.
Deleting all commands of a specific day
• Scroll through the display until the desired day is followed by a horizontal arrow. Press the
key ‘Del’; a question to confirm the deleting operation will appear.
Deleting a specific command
• Scroll through the display until the command to be deleted is followed by a horizontal arrow.
Press the key ‘Del’; a question to confirm the deleting operation will appear.
Instruction book
API161475 37
