Digital outputs
Number of outputs 6 (Elektronikon® controller - p.n. 1900 5200 00 …. 1900 5200 09)
9 (Elektronikon® Graphic controller - p.n. 1900 5200 10 …. 1900 5200 19)
Type Relay (voltage free contacts)
Rated voltage AC 250 V AC / 10 A max.
Rated voltage DC 30 V DC / 10 A max.
Digital inputs
Number of inputs 4 (Elektronikon® controller - p.n. 1900 5200 00 …. 1900 5200 09)
10 (Elektronikon® Graphic controller - p.n. 1900 5200 10 …. 1900 5200 19)
Supply by controller 24 V DC
Supply protection Short circuit protected to ground
Input protection Not isolated
Analog inputs
Number of pressure inputs 1 (Elektronikon® controller - p.n. 1900 5200 00 …. 1900 5200 09)
2 (Elektronikon® Graphic controller - p.n. 1900 5200 10 …. 1900 5200 19)
Number of temperature inputs 3 (Elektronikon® controller - p.n. 1900 5200 00 …. 1900 5200 09)
5 (Elektronikon® Graphic controller - p.n. 1900 5200 10 …. 1900 5200 19)
