Technical specifications
HB 2000, HB 2000 DP HB 2500, HB 2500 DP
Carrier weight class
1) 22 - 38 t
48,502 - 83,776 lbs
27 - 46 t
59,525 - 101,413 lbs
Service weight
2) 2,000 kg
4,409 lbs
2,500 kg
5,512 lbs
Delivery weight (Standard version)
4) 1,638 kg
3,611 lbs
2,050 kg
4,520 lbs
Delivery weight (DustProtector version)
4) 1,714 kg
3,779 lbs
2,112 kg
4,656 lbs
Oil flow rate 150 - 190 l/min
39.6 - 50.2 gal/min
170 - 220 l/min
44.9 - 58.1 gal/min
Operating pressure 160 - 180 bar
2,320 - 2,610 psi
160 - 180 bar
2,320 - 2,610 psi
Impact rate AutoControl
300 - 625 blows/min
AutoControl
280 - 580 blows/min
Working tool diameter 145 mm
5.71 in.
155 mm
6.10 in.
Working length of working tool (Standard version) 665 mm
26.18 in.
680 mm
26.77 in.
Working length of working tool (DustProtector version) 600 mm
23.62 in.
640 mm
25.20 in.
Max. hydraulic input power 57 kW 66 kW
Back pressure acceptance
8) 30 bar 30 bar
Gas pressure HP- accumulator (20 °C) 60 bar 60 bar
Air pressure (min. gauge pressure in percussion chamber)
5) 1.5 bar 1.5 bar
Air flow (up to depth of 10 meters)
6)
4 m
3
/min 4 m
3
/min
Max static pressure (pressure relief valve on carrier) 200 bar 200 bar
Piston accumulator gas pressure (min, at operating temperature
60-70 °C)
7)
12.3 bar 11.6 bar
Piston accumulator gas pressure (max (optimum), at operating
temperature 60-70 °C)
7)
14.8 bar 15.1 bar
Hose inside diameter »P« 25 mm
1 in.
25 mm
1 in.
Hose inside diameter »T« 25 mm
1 in.
25 mm
1 in.
Start up mode StartSelect StartSelect
Part number (Standard version) 3363 1027 61
3363 1168 56
3363 0926 91
3363 1168 58
Part number (DustProtector version) 3363 1044 17
3363 1168 57
3363 0938 71
3363 1168 59
1)
Weights apply to standard carriers only. Any variances must be agreed with Atlas Copco and/or the carrier manufacturer prior to
attachment
2)
Hydraulic breaker incl. breaker box, working tool and adapter plate of medium size.
Please note that the service weight can be considerably higher, depending on the adapter plate.
4)
Hydraulic breaker, breaker box and ContiLube
®
II without working tool and adapter plate
5)
Air pressure at pressure regulator has to be adjusted to 1.5 bar plus 0.1 bar per meter depth
6)
Air flow for depth of more than 10 meters: Flow = 0.1 x depth [m] x flow up to 10 meters [m
3
/min]
7)
Hydraulic breaker in horizontal position, no pressure applied to working tool
8)
Back pressure acceptance when breaker still runs regular but at significant reduced performance (oil flow)
Safety and operating instructions HB 2000, 2000 DP, 2500, 2500 DP
66 © Construction Tools GmbH | 3390 5090 01 | 2016-05-23
Original instructions
