- 16 -
2.2 Markings
Markings provide instructions and information. They
also warn of hazards. For convenience and safety,
keep all markings in legible condition, replacing them
when damaged or missing. Replacement markings are
available from the factory.
A brief description of all markings provided on the
light tower is given hereafter. The precise location of
all markings can be found in the parts manual of this
light tower.
Indicates that an electric voltage,
dangerous to life, is present. Never
touch the electric terminals during
operation.
Indicates that these parts can become
very hot during operation (e.g.
engine, cooler, etc.). Always make
sure that these parts are cooled down
before touching them.
Indicates a risk of fire. This label is
required for On Road transport into
the European Union according to the
European agreement concerning
international carriage of Dangerous
goods by Road, Annex A.
Indicates that the mast should not be
extended near electric wires.
Indicates the locking pin of the
stabilizers.
Indicates the forklift slots.
Indicates the drain plug for the
engine fuel.
Indicates the drain for the
engine oil.
Indicates that the light tower
may be refuelled with diesel
fuel only.
Use PAROIL E only.
Indicates the sound power level in
accordance with Directive 2000/14/
EC (expressed in dB (A)).
Indicates that the alternator should
not be cleaned with high pressurised
water.
Indicates that the unit may
start automatically and
that the instruction book
has to be consulted prior
to use.
