Atlas Copco HiLight H6+ Kd ESF User Manual

- 74 -
7.4.16 Auto tilt (compliant with
SmartMast)
The auto tilt option allows to set the inclination angle
of the floodlights via the control panel.
For cubicle with Lc1003™ controller
For cubicle with Lc1001™ controller
S30 ..... Auto tilt switch
Turn the switch to UP to increase the
inclination angle of the floodlights.
Turn the switch to DOWN to decrease the
inclination angle of the floodlights.
A2 ....... Actuator DC supply and control
7.4.17 Lamps: LED 4 x 350W 48V
(HiLight H6+)
7.4.18 Lamps: LED 4 x 320W 48V
(HiLight H6+ DC)
S50
S51
S20
0
1
H16
Q2 Q3 Q4 Q5Q1 Q6
P7
AUTO MAN
F10
AUTO MAN
S30
A1
F10
000000.00
H2
P1
H16
H3
1 1 1 1N1 1
S30
ECU
S30
