10.2 Technical specifications of the engine/alternator/unit HiLight H6+ DC
Reference conditions 1) Generator service duty COP
Absolute inlet pressure 1 bar
Relative humidity 30%
Air inlet temperature 25°C
Limitations 2) Maximum ambient temperature 40°C
Altitude capability 3000 m
Maximum relative air humidity 80%
Minimum operating temperature -10°C
Minimum operating temperature with cold start equipment (optional) -20°C
Performance data 2) 3) 4) 5) Model name
HiLight H6+ DC
Light coverage (average 18 luxes)
6000 m²
Rated voltage
48 VDC
Power output (all floodlights ON)
1,28 kW
Operating temperature (min)
-20°C
Operating temperature (max)
40°C
Altitude capability
3000 m
Relative air humidity maximum
80%
Minimum starting temperature unaided
-10°C
Minimum starting temperature aided
-20°C
Maximum sound power level (LWA) complies with 2000/14/EC - 50 Hz
82 dB(A)
Sound pressure level (LpA) at 7 m 52 dB(A)
Fuel consumption (all floodlights ON)
0,615 kg/h
Autonomy (all floodlights ON)
168 h
Fuel tank capacity
120 l
Oil service interval
600 h
Mast height
7,6 ±0,3 m
Mast type
hydraulic
Wind speed stability according to EN 1991-1-4:2005+A (terrain category I)
70 km/h
Wind speed stability according to EN 1991-1-4:2005+A (terrain category IV)
105 km/h
Towing speed
100 km/h
