Atlas Copco HiLight H6+ Kd ESF User Manual

- 78 -
10 Technical specifications of the light tower
10.1 Technical specifications of the engine/alternator/unit HiLight H6+
Reference conditions Generator service duty PRP
Absolute inlet pressure 1 bar
Relative humidity 30%
Air inlet temperature 25°C
Performance data Model name
HiLight H6+ KD
Light coverage (average 20 luxes)
6000 m²
Rated frequency
50 Hz
Rated voltage
230 VAC
Power output
2,24 kW
Operating temperature (min)
-20°C
Operating temperature (max)
40°C
Altitude capability
3000 m
Relative air humidity maximum
80%
Minimum starting temperature unaided
-10°C
Minimum starting temperature aided
-20°C
Maximum sound power level (LWA) complies with 2000/14/EC - 50 Hz
83 dB(A) STD
84 dB(A) Spark Arrestor
Sound pressure level (LpA) at 7 m MKT
Fuel consumption
MKT
Autonomy
MKT
Fuel tank capacity
120 l
Oil service interval
MKT
Mast height
7,6 ±0,3 m
Mast type
hydraulic
Wind speed stability according to EN 1991-1-4:2005+A (terrain category I)
70 km/h
Wind speed stability according to EN 1991-1-4:2005+A (terrain category IV)
105 km/h
Towing speed
100 km/h
Standard instrumentation
MKT
Rated power (PRP) - 50 Hz
2,24 kW
00_00_HiLight H6+_EN.book Page 78 Friday, June 4, 2021 11:52 AM
