Figure 5: SF 4
+
Full-Feature, details
Reference Description
AF Inlet air filter
AV Air outlet valve
Ca Air cooler
CV Check valve
Dm Manual drain valve
E Compressor element
ID Refrigerant dryer
M Motor
SV Safety valve
TSHH Temperature sensor
