4. Replace the fuses.
5. Adjust the overload relay settings. See section Settings of overload relay and fuses.
4.4 Pictographs
Pictographs
Reference
Description
1
Warning: the compressor starts and stops automatically. Do not perform service
when pressurized and when the voltage is on.
Read the instruction book, switch off the power and depressurize the
compressor before maintenance or repair.
2
After power failure during automatic operation, the unit restarts automatically.
3 Warning: rotating fan
4 Warning: supply voltage
5 Warning: hot surface
6
Do not adjust the pressure switch while it is depressurized because this can
damage the switch (only for compressors controlled by a pressure switch).
7
Warning: rotating fan
Warning: safety valve blowing
8
Warning: rotating fan
Warning: belts
9
Warning: before connecting the compressor electrically, consult the instruction
book for the motor rotation direction.
Alternative for label 1:
Instruction book
56 2920 7219 10
