Unit ZR55 ZR75 ZR90
Cooling water consumption at temperature
rise of 15 ˚C, ZR Full-Feature
cfm 2.96 3.81 4.45
Cooling water consumption at temperature
rise of 27 ˚F, ZR Full-Feature
cfm 2.96 3.81 4.45
ZR - 10 bar - 50Hz
Unit ZR55 ZR75 ZR90
Nominal working pressure bar 9 9 9
Nominal working pressure psi 130.54 130.54 130.54
Maximum working pressure, ZR Pack bar 10 10 10
Maximum working pressure, ZR Pack psi 145.04 145.04 145.04
Maximum working pressure, ZR Full-
Feature
bar 9.75 9.75 9.75
Maximum working pressure, ZR Full-
Feature
psi 141.41 141.41 141.41
Power input at maximum working pressure,
ZR Pack
kW 61.3 84.6 99.4
Power input at maximum working pressure,
ZR Pack
hp 82.20 113.45 133.30
Power input at maximum working pressure,
ZR Full-Feature
kW 60.8 84.0 98.7
Power input at maximum working pressure,
ZR Full-Feature
hp 81.53 112.64 132.36
Oil capacity l 35 35 35
Oil capacity Us gal 9.24 9.24 9.24
Oil capacity Imp gal 7.70 7.70 7.70
Oil capacity cu.ft 1.23 1.23 1.23
Cooling water consumption at temperature
rise of 15 ˚C, ZR Pack
l/s 0.9 1.2 1.5
Cooling water consumption at temperature
rise of 27 ˚F, ZR Pack
l/s 0.9 1.2 1.5
Cooling water consumption at temperature
rise of 15 ˚C, ZR Pack
cfm 1.91 2.54 3.18
Cooling water consumption at temperature
rise of 27 ˚F, ZR Pack
cfm 1.91 2.54 3.18
Cooling water consumption at temperature
rise of 15 ˚C, ZR Full-Feature
l/s 1.4 1.8 2.1
Instruction book
131
