Always consult your Atlas Copco Customer Centre in case any timer should be changed. The
intervals must not exceed the programmed nominal values.
3.18 Programming clock function
Control panel
Function
To program:
• Time-based start/stop commands for the compressor
• Time-based change-over commands for the net pressure band
Programming start, stop and pressure band commands
In this example, the compressor will be programmed as follows:
• On Monday at 06:15 starting in pressure band 1
• On Friday at 18:00 changing over to pressure band 2
• On Saturday at 18:00 stopping
Starting from the Main screen (see Main screen menu):
• Press the key “Menu” (F1).
• Press the arrow down key (1) until “Modify Parameters” is followed by a horizontal arrow.
• Activate the menu by pressing tabulator key (2).
• Use the arrow down key (1) to scroll until the option “Clock Function” is followed by a horizontal arrow.
• Activate the menu by pressing tabulator key (2); following screen appears:
Instruction book
60
