“Clock Function”
“Not Activated”
.
“Menu” “Modify” “Delete”
F1 F2 F3
• Press the tabulator key (2), following screen appears:
“Monday”
“Tuesday”
“Wednesday”
“Menu” “Delete”
F1 F2 F3
• Use the scroll keys (1) until the day on which a command must be programmed is followed by a horizontal
arrow. Press the tabulator key (2); following screen appears:
--:-- ----------------------
--:-- ----------------------
--:-- ----------------------
“Menu” “Modify” “Delete”
F1 F2 F3
• Press the key “Modify” (F2). The first two dashes will flash. Use the scroll keys (1) to enter “06”. Press
the tabulator key (2) to jump to the following two dashes. Use the scroll keys to enter “15”. Press the
tabulator key to jump to the row of dashes. Use the scroll keys to enter the command “Start Compressor”.
• Press the key “Program” to program the command : “06:15 Start Compressor”.
• Press the arrow down key (1): the horizontal arrow indicates that the second line is accessible. Press the
key “Modify” and modify this line in a similar way to the following command: ”06:15 Pressure Band 1”.
• Press the key “Menu” (F1) and scroll to “Friday”:
“Thursday”
“Friday”
“Saturday”
“Menu” “Delete”
F1 F2 F3
• Programming the command to change over at 18 o’clock to “Pressure Band2” is carried out in a similar
way as described above.
• Press the key “Menu” (F1) and scroll to “Saturday”. Programming the command “18:00 Compressor Stop”
is carried out in a similar way as described above.
Activating/deactivating the timer
• The timer can only be activated if at least one start/stop command is programmed.
• Starting from the Main screen, press the key “Menu” (F1).
• Use arrow down key (1) until the option “Modify Parameters” is followed by a horizontal arrow.
Instruction book
61
