• Press the tabulator key (2) to activate the menu.
• Use the arrow down key until the option “Clock Function” is followed by a horizontal arrow, press the
tabulator key (2), following screen appears:
“Clock Function”
“Not Activated”
.
“Menu” “Modify” “Delete”
F1 F2 F3
• Press the key “Modify”, “Not Activated” starts blinking.
• Press the arrow down key (1) “Not Activated” changes to “Activated”.
• Press the key “Program”.
It is necessary to program the start/stop commands in successive order timewise. Program
the commands from Monday till Sunday, e.g.:
•
07.30 Start Compressor
•
07.30 Pressure Band 1
•
08.30 Pressure Band 2
•
18.00 Stop Compressor
Make sure that the timer function is activated (“Activated”). If not, the programmed start/stop
commands will not be executed.
The timer can be deactivated again. In this case, the programmed start/stop commands will
not be executed (but remain in the memory of the regulator).
Modifying a command
Suppose the command to stop the compressor on Saturday 18:00 is to be modified, i.e. stopping at 17 o'clock
instead of 18 o'clock.
• Starting from the Main screen, press the key “Menu” (F1), press the arrow down key (1) until the option
“Modify Parameters” is followed by a horizontal arrow.
• Activate the menu by pressing the tabulator key (2).
• Use the arrow down key (1) to scroll until the option “Clock Function” is followed by a horizontal arrow.
Press the tabulator key, following screen appears:
“Clock Function”
“Not Activated”
.
“Menu” “Modify” “Delete”
F1 F2 F3
• Press the tabulator key (2), following screen appears:
Instruction book
62
