Minimum
setting
Factory
setting
Maximum
setting
Compressor element 2 inlet temperature
(shut-down level)
˚F 151 158 176
Oil temperature (shut-down warning level) ˚C 40 65 80
Oil temperature (shut-down warning level) ˚F 104 149 176
Oil temperature (shut-down level) ˚C 40 70 80
Oil temperature (shut-down level) ˚F 104 158 176
Service warning level for DP, air filter mbar 100 44 44
Service warning level for DP, air filter psi 1.45 0.6 0.6
Delay at signal, DP air filter sec 0 60 255
Dryer inlet temperature (warning level) ˚C 53 53 58
Dryer inlet temperature (warning level) ˚F 127 127 136
Dryer regeneration air inlet temperature
(warning level)
˚C 100 110 110
Dryer regeneration air inlet temperature
(warning level)
˚F 212 230 230
Calculated Delta T, dryer element (warning
level)
˚C 90 100 100
Calculated Delta T, dryer element (warning
level)
˚F 194 212 212
Service plans
Minimum
setting
Factory
setting
Maximum
setting
Service plan A (running hours) hr See remark 4000 See remark
Service plan A (running hours) hr See remark 3600 See remark
Service plan B (running hours) hr See remark 8000 See remark
Service plan C (running hours) hr See remark 16000 See remark
Service plan I (running hours) hr See remark 2000 See remark
Remark
A number of service operations are grouped (Level A, Level B, ...). Each level stands for a number of service
operations to be carried out at the intervals programmed. Consult your Atlas Copco Service Centre.
Terminology
Term Explanation
ARAVF Automatic restart after voltage failure.See Elektronikon regulator.
Compressor
element 1/2
Element 1 stands for the low-pressure compressor element; element 2 stands for the high-
pressure compressor element.
The regulator does not accept illogical settings, e.g. if the warning level is programmed at
205 ˚C, the minimum limit for the shut-down level changes into 206 ˚C. The recommended
difference between the warning level and shut-down level is 10 ˚C.
Instruction book
71
