Ref Name
1 Start
2 Scroll keys
3 Tabulator key
4 Voltage on
5 Alarm
6 Automatic operation
7 Stop
8 Automatic condensate outlet, intercooler
9 Automatic condensate outlet, aftercooler
10 Warning: under tension
11 Read Instruction book before starting the compressor
12 Switch off the voltage and depressurize the compressor before maintenance or repair
13 Before connecting the compressor electrically, consult the Instruction book for the motor
rotation direction
14 Torques for steel (Fe) or brass (CuZn) bolts
15 Consult the Instruction book before greasing
16 Switch off the voltage before removing the protecting cover inside the electric cabinet
17 Oil the gaskets, screw on the filters and tighten by hand (approx. one half turn)
18 Consult the Instruction book before maintenance or repair
19 Cooling water inlet
20 Cooling water outlet
S2 Emergency stop
Instruction book
94
