4.5.6 External Memory Control Register A – XMCRA
• Bit 7 – SRE: External SRAM/XMEM Enable
Writing SRE to one enables the External Memory Interface.The pin functions AD7:0, A15:8,
ALE, WR
, and RD are activated as the alternate pin functions. The SRE bit overrides any pin
direction settings in the respective data direction registers. Writing SRE to zero, disables the
External Memory Interface and the normal pin and data direction settings are used. Note that
when the XMEM interface is disabled, the address space above the internal SRAM boundary is
not mapped into the internal SRAM.
• Bit 6..4 – SRL2, SRL1, SRL0: Wait-state Sector Limit
It is possible to configure different wait-states for different External Memory addresses. The
external memory address space can be divided in two sectors that have separate wait-state bits.
The SRL2, SRL1, and SRL0 bits select the split of the sectors, see Table 4-3 and Figure 4-4. By
default, the SRL2, SRL1, and SRL0 bits are set to zero and the entire external memory address
space is treated as one sector. When the entire SRAM address space is configured as one sec-
tor, the wait-states are configured by the SRW11 and SRW10 bits.
Note: 1. See Table 4-1 on page 18 for “XMem start” setting.
Bit 76543210
SRE SRL2 SRL1 SRL0 SRW11 SRW10 SRW01 SRW00 XMCRA
Read/Write R/W R/W R/W R/W R/W R/W R/W R/W
Initial Value00000000
Table 4-3. Sector limits with different settings of SRL2..0
SRL2 SRL1 SRL0 Sector Addressing
000
Lower sector N/A
Upper sector “XMem start”
(1)
- 0xFFFF
001
Lower sector “XMem start”
(1)
- 0x1FFF
Upper sector 0x2000 - 0xFFFF
010
Lower sector “XMem start”
(1)
- 0x3FFF
Upper sector 0x4000 - 0xFFFF
011
Lower sector “XMem start”
(1)
- 0x5FFF
Upper sector 0x6000 - 0xFFFF
100
Lower sector “XMem start”
(1)
- 0x7FFF
Upper sector 0x8000 - 0xFFFF
101
Lower sector “XMem start”
(1)
- 0x9FFF
Upper sector 0xA000 - 0xFFFF
110
Lower sector “XMem start”
(1)
- 0xBFFF
Upper sector 0xC000 - 0xFFFF
111
Lower sector “XMem start”
(1)
- 0xDFFF
Upper sector 0xE000 - 0xFFFF
