Atmel AVR AT90CAN32 User Manual

407
7679H–CAN–08/08
AT90CAN32/64/128
(0x7C) ADMUX REFS1 REFS0 ADLAR MUX4 MUX3 MUX2 MUX1 MUX0 page 287
(0x7B) ADCSRB –ACME – – – ADTS2 ADTS1 ADTS0 page 291, 269
(0x7A) ADCSRA ADEN ADSC ADATE ADIF ADIE ADPS2 ADPS1 ADPS0 page 289
(0x79) ADCH - / ADC9 - / ADC8 - / ADC7 - / ADC6 - / ADC5 - / ADC4 ADC9 / ADC3 ADC8 / ADC2 page 290
(0x78) ADCL ADC7 / ADC1 ADC6 / ADC0 ADC5 / - ADC4 / - ADC3 / - ADC2 / - ADC1 / - ADC0 / page 290
(0x77) Reserved
(0x76) Reserved
(0x75) XMCRB XMBK – – – – XMM2 XMM1 XMM0 page 33
(0x74) XMCRA SRE SRL2 SRL1 SRL0 SRW11 SRW10 SRW01 SRW00 page 32
(0x73) Reserved
(0x72) Reserved
(0x71) TIMSK3 – –ICIE3– OCIE3C OCIE3B OCIE3A TOIE3 page 142
(0x70) TIMSK2 – – – – – – OCIE2A TOIE2 page 162
(0x6F) TIMSK1 – –ICIE1– OCIE1C OCIE1B OCIE1A TOIE1 page 142
(0x6E) TIMSK0 – – – – – – OCIE0A TOIE0 page 112
(0x6D) Reserved
(0x6C) Reserved
(0x6B) Reserved
(0x6A) EICRB ISC71 ISC70 ISC61 ISC60 ISC51 ISC50 ISC41 ISC40 page 94
(0x69) EICRA ISC31 ISC30 ISC21 ISC20 ISC11 ISC10 ISC01 ISC00 page 93
(0x68) Reserved
(0x67) Reserved
(0x66) OSCCAL – CAL6 CAL5 CAL4 CAL3 CAL2 CAL1 CAL0 page 42
(0x65) Reserved
(0x64) Reserved
(0x63) Reserved
(0x62) Reserved
(0x61) CLKPR CLKPCE – – – CLKPS3 CLKPS2 CLKPS1 CLKPS0 page 44
(0x60) WDTCR – – – WDCE WDE WDP2 WDP1 WDP0 page 58
0x3F (0x5F) SREG ITHSVNZ C page 11
0x3E (0x5E) SPH SP15 SP14 SP13 SP12 SP11 SP10 SP9 SP8 page 14
0x3D (0x5D) SPL SP7 SP6 SP5 SP4 SP3 SP2 SP1 SP0 page 14
0x3C (0x5C) Reserved
0x3B (0x5B) RAMPZ
(1)
– – – – – – – RAMPZ0 page 13
0x3A (0x5A) Reserved
0x39 (0x59) Reserved
0x38 (0x58) Reserved
0x37 (0x57) SPMCSR SPMIE RWWSB – RWWSRE BLBSET PGWRT PGERS SPMEN page 326
0x36 (0x56) Reserved – – – – – – – –
0x35 (0x55) MCUCR JTD – –PUD– – IVSEL IVCE page 64, 73, 304
0x34 (0x54) MCUSR – – – JTRF WDRF BORF EXTRF PORF page 56, 304
0x33 (0x53) SMCR – – – –SM2SM1SM0SE page 46
0x32 (0x52) Reserved
0x31 (0x51) OCDR IDRD/OCDR7 OCDR6 OCDR5 OCDR4 OCDR3 OCDR2 OCDR1 OCDR0 page 299
0x30 (0x50) ACSR ACD ACBG ACO ACI ACIE ACIC ACIS1 ACIS0 page 270
0x2F (0x4F) Reserved
0x2E (0x4E) SPDR SPD7 SPD6 SPD5 SPD4 SPD3 SPD2 SPD1 SPD0 page 175
0x2D (0x4D) SPSR SPIF WCOL
– – – – –SPI2X page 175
0x2C (0x4C) SPCR SPIE SPE DORD MSTR CPOL CPHA SPR1 SPR0 page 173
0x2B (0x4B) GPIOR2 GPIOR27 GPIOR26 GPIOR25 GPIOR24 GPIOR23 GPIOR22 GPIOR21 GPIOR20 page 36
0x2A (0x4A) GPIOR1 GPIOR17 GPIOR16 GPIOR15 GPIOR14 GPIOR13 GPIOR12 GPIOR11 GPIOR10 page 36
0x29 (0x49) Reserved
0x28 (0x48) Reserved
0x27 (0x47) OCR0A OCR0A7 OCR0A6 OCR0A5 OCR0A4 OCR0A3 OCR0A2 OCR0A1 OCR0A0 page 112
0x26 (0x46) TCNT0 TCNT07 TCNT06 TCNT05 TCNT04 TCNT03 TCNT02 TCNT01 TCNT00 page 111
0x25 (0x45) Reserved
0x24 (0x44) TCCR0A FOC0A WGM00 COM0A1 COM0A0 WGM01 CS02 CS01 CS00 page 109
0x23 (0x43) GTCCR TSM
– – – – – PSR2 PSR310 page 98, 164
0x22 (0x42) EEARH
(2)
– – – – EEAR11 EEAR10 EEAR9 EEAR8 page 22
0x21 (0x41) EEARL EEAR7 EEAR6 EEAR5 EEAR4 EEAR3 EEAR2 EEAR1 EEAR0 page 22
0x20 (0x40) EEDR EEDR7 EEDR6 EEDR5 EEDR4 EEDR3 EEDR2 EEDR1 EEDR0 page 23
0x1F (0x3F) EECR – – – – EERIE EEMWE EEWE EERE page 23
0x1E (0x3E) GPIOR0 GPIOR07 GPIOR06 GPIOR05 GPIOR04 GPIOR03 GPIOR02 GPIOR01 GPIOR00 page 36
0x1D (0x3D) EIMSK INT7 INT6 INT5 INT4 INT3 INT2 INT1 INT0 page 95
0x1C (0x3C) EIFR INTF7 INTF6 INTF5 INTF4 INTF3 INTF2 INTF1 INTF0 page 95
0x1B (0x3B)
Reserved
Address Name Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0 Page
