Parts Identification
Parts Identification[2]
Main Body2-1.
10A10A
BREAKER
UPS
120V~ 60Hz
①
④
③
⑤
⑥
⑬
⑨
⑤
⑫
⑪
⑩
✽
⑧
⑦
②
⑭
⑮
⑯
⑰
⑱
No. Name
①
Canopy
②
Lighting lamp
③
Mattress
④
Baby guard
⑤
Foot switch
⑥
Caster
⑦
Mattress platform tilting lever
⑧
Mattress platform
⑨
Tube introduction slit packing
No. Name
⑩
*
Resuscitator
⑪
Operation panel
⑫
Alarm lamp
⑬
Heater
⑭
Canopy fixing screw
⑮
I/O port (communication connector)
⑯
Breaker
⑰
Connector for the Power Pack i (UPS)
⑱
AC inlet
* The figure shows the unit in which a commercially available resuscitation unit and a commercially available
blender unit are installed. For information on the resuscitation unit and the blender unit, see their operation
manuals respectively.
