INSTRUMENTS
1)
Turning indicator light
“
”
The light
fl
ashes when activating the left or right hand turning indi-
cator using the control lever on the left-hand switch.
2)
High-beam light
“
”
The light comes on when activating the high-beam light using the
control on the left-hand switch.
3)
Neutral warning light
“
”
The light comes on when the gear shift lever is in neutral position (no
gear engaged).
4)
Engine failure warning light
“
”
When the ignition switch is in the "on" position, and all other start
conditions have been satisfied (see "Start Conditions" for more
information), the Diagnostic Trouble Code light (red "check engine"
light) will illuminate and stay lit until the engine has been started.
This is a "Lamp Test" to allow you to check the function of the indi-
cator bulb.
Once the engine has been started, the light will turn off unless the
ECU has detected a fault. If the light remains illuminated or flashes
when the engine is running, a fault condition exists. Contact an
authorized genuine dealer for service.
If the indicator light does not come on at all, check the indicator bulb
and replace if necessary.
5)
Fuel gauge
when the ignition key is turned, the light comes on for a few seconds
and then goes o
ff
.
6)
Speed indicator
Indicate motorcycle speed (Km/h). Do not exceed legal rate-limiting
to assure safe riding.
7)
Odometer
Indicate riding distance (Km).
8)
RPM indicator
The instrument RPM instructions with stepper motor indicator. The
indicated span 0-10000RPM
Turn the ignition switch to the "on" position. The tachometer will
sweep to the Redline and back indicating that the tachometer needle
is functioning properly.
CAUTION
If you exceed 8000 rpm (red area), the engine may be damaged.
