Definition ECU pins
1 J1-1 IACAHi 1 J2-1 COILA
2 J1-2 MAGNETO CUT RELAY 2 J2-2 GND
3 J1-3 MIL 3 J2-3 KW2000
4 J1-4 4 J2-4 CRANK HI
5 J1-5 5 J2-5 INJA
6 J1-6 TACH 6 J2-6
7 J1-7 CANLo 7 J2-7 O2AHTR
8 J1-8 CANHi 8 J2-8 IAT_MAT
9 J1-9 GND 9 J2-9 FUEL PUMP RELAY
10 J1-10 10 J2-10 5VRTN
11 J1-11 IACALo 11 J2-11 MAP
12 J1-12 IACBHi 12 J2-12 TPS
13 J1-13 IACBLo 13 J2-13 CRANK LO
14 J1-14 14 J2-14 CLT
15 J1-15 15 J2-15 IGN
16 J1-16 DIAG 16 J2-16 5VREF
17 J1-17 FUEL PUMP RECIRCULATION 17 J2-17 O2A
18 J1-18 PNSW 18 J2-18 VBATT
