50
Major Components of EFI system
Intake air pressure sensor
Throttle position sensor
ECM
Fuel Injector
Cylinder Head Temperature Sensor
Oxygen sensor
Stepper motor
Throttle body
Air intake pipe
Fuel pump
Fuel filter
