ATX 125 - Special Torque Values

46
Special Torque Values
Item Quantity Thread diameter (mm) Torque value (ft-lb)
Cylinder head nut 4
M10 × 1.25 21-24
Magneto flywheel fastening nut 1
M10 × 1.25 27-33
Spark Plug 1
M12 × 1.25 13-15
Front wheel axle 1 14
30-37
Real wheel axle nut 1 16
44-66
Swing arm shaft nut 1
14 44-52
Engine hanging bolt 3 10
29-36
Engine cover bolt
6 8
18-26
Steering handlebar clamp bolt 4 8
15-22
Front fork tube cap nut 1 21
44-52
Brake disc bolt 6
M8×25
15-22
