ATX 125 - Page 51

47
Standard Torque Values
Name and dimensions Torque value (ft-lb)
5mm bolt & nut
3.5 - 4.5
6mm bolt & nut
6 - 9
8mm bolt & nut
13 - 18
10mm bolt & nut
22 - 30
12mm bolt & nut
37 - 44
5mm Screw
2.5 - 3.5
6mm Screw
5 - 8
6mm spool bolt & nut
7 - 10
8mm spool bolt & nut
15 - 22
10mm spool bolt & nut
22 - 30
