PUSHBUTTON OPERATIONS
3-2 TranScend Chassis – Operation Manual
NOTE: Only after pressing the Select button, the gain settings option is operated on the selected
channel.
• Select to commit the setting to NVRAM
Example #1: In the “Gain Setting Menu”, if cursor is on “Save: No (17)”, user must toggle the right or left
button to change the option to “Yes”. Then press “Select” to commit the value, 17, in the bracket into the
NVRAM.
NOTE: Only if the value is committed into NVRAM, the chassis will use the selected gain level next
time the chassis recovers from power cycle.
3.1.2 Combination Button Operations
The combination button operations are unique to TranScend chassis. Each combination operation is de ned strictly for their
speci c usage as the following de nition.
UP+DOWN: When pressing and holding the UP+DOWN button simultaneously when traversing the slot menu, the front
panel displays current slot number. The front panel display will restore back to the previous display once the button
combination is released.
Example #1: User is within the “Status Menu” of slot #1, press and hold the Up and Down buttons, the front panel
displays “Current Slot: 1”. The “Status Menu” returns after releasing the Up and Down button combinations.
LEFT+RIGHT: When pressing and holding the LEFT+RIGHT button simultaneously, the front panel displays tree’s top menu
of sub-tree. The top menu is usually the module’s Greetings.
NOTE: The support of this feature starts on plugin software version 2.1D or later.
