FRONT PANEL LCD DISPLAY
4-6 TranScend Chassis – Operation Manual
4.3.3 Quad Return Receiver
Level 1 Level 2 Level 3 Level 4
Greeting Setup Attn Setting Select Channel
Attn (dB)
Save
Prev Menu
Test Point Select Channel
Prev Menu
Alarm Enable Channel
Enable
Save
Prev Menu
Prev Menu
Status Optical
Prev Menu
Alarm Receiver Power
Module Temp
Prev Menu
Optical Power (dBm)
Attn (dB)
Prev Menu
Chassis Temperature(C)
Model
Hardware Version
Software Version
Serial Number
Prev Menu
Prev Menu
Prev Menu
Table 4: TranScend Quad Return Receiver Front Panel Display Menu Overview
Greeting:
Greeting Message
Press “Select” button to go into the plug-in menu.
Prev Menu:
Press “Select” will bring back to the System menu.
InnoTrans Communications
Quad Return Rcvr
