ATX TranScend - Optical Switch Attributes; Forward Receiver Attributes; RF Switch Attributes

USER INTERFACE CROSS REFERENCE
TranScend Chassis – Operation Manual 7-3
Optical: Power
(dBm)
OpticalPowerDbm .innoTransTranscendModuleLaserEntry.15
Optical: Laser
Temperature (C)
LaserTemp .innoTransTranscendModuleLaserEntry.3
Optical: Attn (dB) Attenuation .innoTransTranscendModuleLaserEntry.19
Chassis:
Temperature(C)
ModuleTemp .innoTransTranscendModuleEntry.6
7.7 Optical Switch Attributes
Front Panel
Display
CLI SNMP OID SNMP Trap ID
Status: OPin
Pwr(dBm)
OpinPower
.innoTransTranscendModuleLaserEntry.11
Status: Switch Switch
.innoTransTranscendModuleLaserEntry.20
Alarm: OPin Pwr OPinPowerAlarm
.iTTrancendNotication.15
Alarm: Module
Temperature
ModuleTempAlarm .iTTrancendNotication.30
Alarm: Switch SwitchAlarm
.iTTrancendNotication.21
Chassis:
Temperature(C)
ModuleTemp .innoTransTranscendModuleEntry.6
7.8 Forward Receiver Attributes
Front Panel
Display
CLI SNMP OID SNMP Trap ID
Status: Opt
Pwr(dBm)
OpticalPowerDbm .innoTransTranscendModuleLaserEntry.15
Alarm: RF Pwr RFPowerAlarm .iTTrancendNotication.22
Status: Attn (dB) Attenuation .innoTransTranscendModuleLaserEntry.19
Alarm: Opt Power OpticalPowerAlarm .iTTrancendNotication.19
Alarm: Module
Temperature
ModuleTempAlarm .iTTrancendNotication.30
Chassis:
Temperature(C)
ModuleTemp .innoTransTranscendModuleEntry.6
7.9 RF Switch Attributes
Front Panel
Display
CLI SNMP OID SNMP Trap ID
Status: RF
Pwr(dBmV)
RFPower .innoTransTranscendModuleLaserEntry.14
Status: Switch Switch .innoTransTranscendModuleLaserEntry.20
Setup:
Threshold(dBmV)
ThresholddBmV .innoTransTranscendModuleLaserEntry.23
Alarm: RF Pwr RFPowerAlarm .iTTrancendNotication.22
Alarm: Module
Temperature
ModuleTempAlarm .iTTrancendNotication.30
Alarm: Switch SwitchAlarm .iTTrancendNotication.21
Chassis:
Temperature(C)
ModuleTemp .innoTransTranscendModuleEntry.6
CHAPTER 7:
