ATX TranScend - Opto-Stacker

FRONT PANEL LCD DISPLAY
TranScend Chassis – Operation Manual 4-27
Tx Fiber Length Menu:
Length (km): Press “Select” to set the transmit  ber length. Press “Right” or “left” button to increase or decrease
the  ber length.
NOTE: User must press “Select” to select the  ber length in order for the plug-in to operate at
selected  ber length and for NVRAM storage. Fail to do so, the  ber length might revert back to
previous setting.
The factory default: 10
Save: Press “Right” or “Left” button to cycle between “Yes” or “No”. Press “Select” to commit the selection into
NVRAM when “Yes” is selected. The display in bracket re ects the current NVRAM storage reading. If user presses
“Select” when display is “No”, no NVRAM change takes place.
Status Menu:
Laser Temp(C): Displays the current reading of laser temperature in Centigrade.
Laser Pwr(dBm): Displays the current reading of laser power in dBm.
TxRF Lvl(dB): Displays the current reading of TxRF level in dB.
Lambda (nm): Displays the laser wavelength in nano meter.
Tx Attn (dB): Displays the current reading of transmit attenuation in dB.
Volt (V): Displays onboard supply voltage.
Alarm Menu:
Laser Temp: Displays the alarm status of the laser temperature.
Laser Power: Displays the alarm status of laser power.
TxRF Level: Displays the alarm status of TxRF level.
Module Temp: Displays the alarm status of module temperature.
Chassis Menu:
Temp(C): Displays the module’s temperature reading in Centigrade.
Model: Displays the model name of plug-in module.
HW Ver: Displays the hardware version information of plug-in module.
SW Ver: Displays the software version information of plug-in module.
Ser #: Displays the serial number of plug-in module.
Prev Menu:
Press “Select” will bring the plug-in’s greeting message screen back.
4.3.14 Opto-Stacker
Level 1 Level 2 Level 3 Level 4
Greeting Setup Sel Channel
Mode Setting Mode
Save
Prev Menu
Attn Setting Attn(dB)
Save
Prev Menu
Prev Menu
