ATX TranScend - High Sensitivity Opto-Stacker

FRONT PANEL LCD DISPLAY
TranScend Chassis – Operation Manual 4-23
4.3.12 High Sensitivity Opto-Stacker
Level 1 Level 2 Level 3 Level 4
Greeting Setup Sel Ch
Attn Setting GainRsv(dB)
Attn (dB)
Save
Prev Menu
Test Point TP Ch
Prev Menu
Mode Setting Mode
Save
Prev Menu
Prev Menu
Status OptPwr(dBm)
Attn (dB)
Laser Temp(C)
OPout Pwr(dBm)
Gain Resv(dB)
Mode
Prev Menu
Alarm OptPwr
Syn Lock
Laser Temp
OPout Pwr
Module Temp
Prev Menu
Chassis Temperature(C)
Model
Hardware Version
Software Version
Serial Number
Prev Menu
Prev Menu
Prev Menu
Table 13: TranScend High Sensitivity Opto-Stacker Front Panel Display Menu Overview
