ATX TranScend - Quad Return Receiver Attributes; Destacker Attributes; Stacker Attributes

USER INTERFACE CROSS REFERENCE
7-2 TranScend Chassis – Operation Manual
Alarm: Shutoff ShutoffAlarm .iTTrancendNotication.17
Alarm: Module
Temperature
ModuleTempAlarm .iTTrancendNotication.30
Chassis:
Temperature(C)
ModuleTemp .innoTransTranscendModuleEntry.6
7.4 Quad Return Receiver Attributes
Front Panel
Display
CLI SNMP OID SNMP Trap ID
Status: Optical
Alarm: Receiver
Power
OpticalPowerAlarm .iTTrancendNotication.19
Alarm: Module
Temp
ModuleTempAlarm .iTTrancendNotication.30
Optical: Power
(dBm)
OpticalPowerDbm .innoTransTranscendModuleLaserEntry.15
Optical: Attn (dB) Attenuation .innoTransTranscendModuleLaserEntry.19
Chassis:
Temperature(C)
ModuleTemp .innoTransTranscendModuleEntry.6
7.5 DeStacker Attributes
Front Panel
Display
CLI SNMP OID SNMP Trap ID
Alarm: Synthesizer
Lock
LockAlarm .iTTrancendNotication.20
Alarm: Receiver
Power
OpticalPowerAlarm .iTTrancendNotication.19
Alarm: Module
Temperature
ModuleTempAlarm .iTTrancendNotication.30
Optical : Receiver
Power (dBm)
OpticalPowerDbm .innoTransTranscendModuleLaserEntry.15
Optical: Gain Resv
(dB)
GainReserve .innoTransTranscendModuleLaserEntry.18
Optical : Attn (dB) Attenuation .innoTransTranscendModuleLaserEntry.19
Optical: Freq Chnl Mode .innoTransTranscendModuleLaserEntry.21
Chassis:
Temperature(C)
ModuleTemp .innoTransTranscendModuleEntry.6
7.6 Stacker Attributes
Front Panel
Display
CLI SNMP OID SNMP Trap ID
Alarm: Synthesizer
Lock
LockAlarm .iTTrancendNotication.20
Alarm: Optical
Power
OpticalPowerAlarm .iTTrancendNotication.19
Alarm: Laser
Temperature
LaserTempAlarm .iTTrancendNotication.10
Alarm: Module
Temperature
ModuleTempAlarm .iTTrancendNotication.30
CHAPTER 7:
