ATX TranScend - Transceiver

FRONT PANEL LCD DISPLAY
4-20 TranScend Chassis – Operation Manual
4.3.11 Transceiver
Level 1 Level 2 Level 3 Level 4
Greeting Setup Mode Setting Menu Mode
Save
Prev Menu
Tx Gain Setting Menu Gain(steps)
Save
Prev Menu
Tx Fiber Length Menu Length(km)
Save
Prev Menu
Rx Attenuation Menu Attn(dB)
Save
Prev Menu
Prev Menu
Status Laser Temp(C)
Laser Pwr(dBm)
RF Lvl(dB)
OPin Pwr(dBm)
Lambda (nm)
Tx Attn (dB)
Prev Menu
Alarm Laser Temp
Laser Power
OPin Pwr
RF Level
Module Temp
Prev Menu
Chassis Temperature(C)
Model
Hardware Version
Software Version
Serial Number
Prev Menu
Prev Menu
Prev Menu
Table 12: TranScend Transceiver Front Panel Display Menu Overview
