ATX TranScend - High Sensitivity Opto-Stacker; Direct Forward Transmitter (DFB Tx) Attributes

USER INTERFACE CROSS REFERENCE
TranScend Chassis – Operation Manual 7-5
7.12 High Sensitivity Opto-Stacker
Front Panel
Display
CLI SNMP OID SNMP Trap ID
Chassis:
Temperature(C)
ModuleTemp .innoTransTranscendModuleEntry.6
Status: Laser
Temperature (C)
LaserTemp .innoTransTranscendModuleLaserEntry.3
Status: Optical
Output (dBm)
OPoutPower .innoTransTranscendModuleLaserEntry.12
Optical: Power
(dBm)
OpticalPowerDbm .innoTransTranscendModuleLaserEntry.15
Optical: Gain Resv
(dB)
GainReserve .innoTransTranscendModuleLaserEntry.18
Status: Mode Mode .innoTransTranscendModuleLaserEntry.8
Optical: Freq Chnl ChannelMode .innoTransTranscendModuleLaserEntry.21
Alarm: Laser
Temperature
LaserTempAlarm .iTTrancendNotication.10
Alarm: Receiver
Power
OpticalPowerAlarm .iTTrancendNotication.19
Alarm: Optical
Output
OPoutPowerAlarm .iTTrancendNotication.16
Alarm: Syn Lock LockAlarm .iTTrancendNotication.20
Alarm: Module
Temperature
ModuleTempAlarm .iTTrancendNotication.30
7.13 Direct Forward Transmitter (DFB Tx) Attributes
Front Panel Display CLI SNMP OID SNMP Trap ID
Chassis:
Temperature(C)
ModuleTemp .innoTransTranscendModuleEntry.6
Status: Laser
Temperature (C)
LaserTemp .innoTransTranscendModuleLaserEntry.3
Status: Laser Power
(dBm)
LaserPowerDbm .innoTransTranscendModuleLaserEntry.5
Status: Laser RF (dB) LaserRf .innoTransTranscendModuleLaserEntry.2
Status: Laser
Wavelength (nm)
Wavelength .innoTransTranscendModuleLaserEntry.6
Status: Gain offset
(steps)
GainOffset .innoTransTranscendModuleLaserEntry.7
Status: Gain Control
Mode
GainControl .innoTransTranscendModuleLaserEntry.8
Status: Attn (dB) Attenuation .innoTransTranscendModuleLaserEntry.19
Status: Fiber Length
(km)
FiberLength .innoTransTranscendModuleLaserEntry.25
Alarm: Laser
Temperature
LaserTempAlarm .iTTrancendNotication.10
Alarm: Laser Power LaserPowerAlarm .iTTrancendNotication.11
Alarm: Laser RF LaserRfAlarm .iTTrancendNotication.12
Alarm: Module
Temperature
ModuleTempAlarm .iTTrancendNotication.30
CHAPTER 7:
