7.10 AGC EDFA Attributes
The AGC EDFA describes in this document applies to the rmware release 1.21 or later.
Front Panel
Display
CLI SNMP OID SNMP Trap ID
Status: Laser
Temperature (C)
LaserTemp .innoTransTranscendModuleLaserEntry.3
Status: Bias (mA) LaserBias .innoTransTranscendModuleLaserEntry.13
Status: Optical
Input (dBm)
OPinPower .innoTransTranscendModuleLaserEntry.11
Status: Optical
Output (dBm)
OPoutPower .innoTransTranscendModuleLaserEntry.12
Alarm: Laser
Temperature
LaserTempAlarm .iTTrancendNotication.10
Alarm: Optical Input OPinPowerAlarm .iTTrancendNotication.15
Alarm: Gain GainAlarm .iTTrancendNotication.18
Alarm: Shutoff ShutoffAlarm .iTTrancendNotication.17
Alarm: Module
Temperature
ModuleTempAlarm .iTTrancendNotication.30
Chassis:
Temperature(C)
ModuleTemp .innoTransTranscendModuleEntry.6
7.11 Transceiver Attributes
Front Panel
Display
CLI SNMP OID SNMP Trap ID
Status: Laser
Temperature (C)
LaserTemp .innoTransTranscendModuleLaserEntry.3
Status: Laser
Power (dBm)
LaserPowerDbm .innoTransTranscendModuleLaserEntry.5
Status: Laser RF
(dB)
LaserRf .innoTransTranscendModuleLaserEntry.2
Status: Laser
Wavelength (nm)
Wavelength .innoTransTranscendModuleLaserEntry.6
Status: Optical
Input (dBm)
OPinPower .innoTransTranscendModuleLaserEntry.11
Status: Attn (dB) Attenuation .innoTransTranscendModuleLaserEntry.19
Status: Gain offset
(steps)
GainOffset .innoTransTranscendModuleLaserEntry.7
Status: Gain
Control Mode
GainControl .innoTransTranscendModuleLaserEntry.8
Status: Fiber
Length (km)
FiberLength .innoTransTranscendModuleLaserEntry.25
Alarm: Laser
Temperature
LaserTempAlarm .iTTrancendNotication.10
Alarm: Laser Power LaserPowerAlarm .iTTrancendNotication.11
Alarm: Laser RF LaserRfAlarm .iTTrancendNotication.12
Alarm: Optical Input OPinPowerAlarm .iTTrancendNotication.15
Alarm: Module
Temperature
ModuleTempAlarm .iTTrancendNotication.30
Chassis:
Temperature(C)
ModuleTemp .innoTransTranscendModuleEntry.6
