ATX TranScend - Direct Forward Transmitter (DFB Tx)

FRONT PANEL LCD DISPLAY
TranScend Chassis – Operation Manual 4-25
Alarm Menu:
OptPwr: Displays the alarm status of optical receiver power.
Syn Lock: Displays the alarm status of the synthesizer lock state.
Laser Temp: Displays the alarm status of the laser temperature.
OPout Pwr: Displays the alarm status of the optical output power.
Module Temp: Displays the alarm status of module temperature.
Chassis Menu:
Temp(C): Displays the module’s temperature reading in Centigrade.
Model: Displays the model name of plug-in module.
HW Ver: Displays the hardware version information of plug-in module.
SW Ver: Displays the software version information of plug-in module.
Ser #: Displays the serial number of plug-in module.
Prev Menu:
Press “Select” will bring the plug-in’s greeting message screen back.
4.3.13 Direct Forward Transmitter (DFB Tx)
Level 1 Level 2 Level 3 Level 4
Greeting Setup Mode Mode
Save
Prev Menu
Tx Gain Setting Gain(Steps)
Save
Prev Menu
Tx Fiber Length Length(Km)
Save
Prev Menu
Prev Menu
Status Laser Temp(C)
Laser Pwr(dBm)
TxRF Lvl(dB)
Lambda (nm)
Tx Attn (dB)
Volt (V)
Prev Menu
Alarm Laser Temp
Laser Power
TxRF Lvl
Mod Temp
Prev Menu
CHAPTER 4:
