FRONT PANEL LCD DISPLAY
TranScend Chassis – Operation Manual 4-19
Gain Setting Menu:
Gain (steps): Press “Select” to set the gain offset. Press “Right” or “left” button to increase or decrease the gain
steps.
NOTE: User must press “Select” to select the gain offset in order for the plug-in to operate at
selected gain offset and for NVRAM storage. Fail to do so, the gain offset might revert back to
previous setting.
The factory default: 0.
Save: Press “Right” or “Left” button to cycle between “Yes” or “No”. Press “Select” to commit the selection into
NVRAM when “Yes” is selected. The display in bracket re ects the current NVRAM storage reading. If user presses
Attn Setting Menu:
Attn (dB): Press “Select” to set the attenuation level. Press “Right” to increase or “Left” button to decrease the
attenuation level.
NOTE: After the attenuation level adjustment, user must press “Select” to commit the attenuation
level in order for the plug-in to operate at such level and for NVRAM storage. Fail to do so, the
attenuation might revert back to previous level.
Save: Press “Right” or “Left” button to select between “Yes” or “No”. Press “Select” to commit the value into
NVRAM when “Yes” is selected. The value in bracket re ects the current NVRAM contetns. If user presses “Select”
when the display is “No”, no NVRAM change takes place.
Alarm Menu:
OPin Power: Displays the alarm status of optical input power.
OPout Power: Displays the alarm status of optical output power.
Gain: Displays the alarm status of gain.
Module Temp: Displays the alarm status of module temperature.
Shutoff: Displays the alarm status of shutoff activity.
Status Menu:
OPin Pwr (dBm): Displays the optical input power reading in dBm.
OPout Pwr (dBm): Displays the optical output power reading in dBm.
Gain (dB): Displays the gain reading in dB.
Volt (V): Displays the on board voltage in V.
Chassis Menu:
Temp(C): Displays the module’s temperature reading in Centigrade.
Model: Displays the model name of plug-in module.
HW Ver: Displays the hardware version information of plug-in module.
SW Ver: Displays the software version information of plug-in module.
Ser #: Displays the serial number of plug-in module.
Prev Menu:
Press “Select” will bring the plug-in’s greeting message screen back.
