FRONT PANEL LCD DISPLAY
TranScend Chassis – Operation Manual 4-21
Greeting:
Greeting Message
Press “Select” button to go into the plug-in menu.
Prev Menu:
Press “Select” will bring back to the System menu.
The entries in plug-in menu are described as follows:
Setup Menu:
Mode Setting Menu:
Mode: Press “Select” to set the gain mode, AGC/MGC. Press “Right” or “left” button to cycle through the
available mode options.
NOTE: User must press “Select” to select the gain mode in order for the plug-in to operate at
selected gain mode and for NVRAM storage. Fail to do so, the gain mode might revert back to
previous setting.
The factory default: MGC
Save: Press “Right” or “Left” button to cycle between “Yes” or “No”. Press “Select” to commit the selection
into NVRAM when “Yes” is selected. The display in bracket re ects the current NVRAM storage reading. If
user presses “Select” when display is “No”, no NVRAM change takes place.
Tx Gain Setting Menu:
Gain (steps): Press “Select” to set the gain offset. Press “Right” or “left” button to increase or decrease the gain
steps.
NOTE: User must press “Select” to select the gain offset in order for the plug-in to operate at
selected gain offset and for NVRAM storage. Fail to do so, the gain offset might revert back to
previous setting.
The factory default: 0.
Save: Press “Right” or “Left” button to cycle between “Yes” or “No”. Press “Select” to commit the selection into
NVRAM when “Yes” is selected. The display in bracket re ects the current NVRAM storage reading. If user presses
“Select” when display is “No”, no NVRAM change takes place.
Tx Fiber Length Menu:
Length (km): Press “Select” to set the transmit ber length. Press “Right” or “left” button to increase or decrease
the ber length.
NOTE: User must press “Select” to select the ber length in order for the plug-in to operate at
selected ber length and for NVRAM storage. Fail to do so, the ber length might revert back to
previous setting.
The factory default: 10
Save: Press “Right” or “Left” button to cycle between “Yes” or “No”. Press “Select” to commit the selection into
NVRAM when “Yes” is selected. The display in bracket re ects the current NVRAM storage reading. If user presses
“Select” when display is “No”, no NVRAM change takes place.
InnoTrans Communications
Transceiver
CHAPTER 4:
