FRONT PANEL LCD DISPLAY
4-12 TranScend Chassis – Operation Manual
Chassis Temperature(C)
Model
Hardware Version
Software Version
Serial Number
Prev Menu
Prev Menu
Prev Menu
Table 7: TranScend Stacker Front Panel Display Menu Overview
Greeting:
Greeting Message
Press “Select” button to go into the plug-in menu.
Prev Menu:
Press “Select” will bring back to the System menu.
The entries in plug-in menu are described as follows:
Setup Menu:
Test Point Menu: Select the test point connection to front panel “RF TEST” output.
Sel Ch: Press “Select” to select the channel to connect to the front panel “RF TEST” output. Press “Right” or “Left”
button to cycle through available channels.
Optical Menu:
Opt Pwr (dBm): Displays the optical power reading in dBm.
RF Level (dB): Displays the RF level in dB.
Attn (dB): Displays the attenuation reading in dB.
Laser Tmp(C): Displays the laser temperature in Centigrade.
Alarm Menu:
Syn Lock: Displays the alarm state of synthesizer lock status.
Press “Right” or “Left” button to cycle through available channels.
Opt Power: Displays the alarm status of optical receiver power.
Laser Temp: Displays the alarm status of laser temperature.
Module Temp: Displays the alarm status of module temperature.
Chassis Menu:
Temp(C): Displays the module’s temperature reading in Centigrade.
Model: Displays the model name of plug-in module.
HW Ver: Displays the hardware version information of plug-in module.
SW Ver: Displays the software version information of plug-in module.
Ser #: Displays the serial number of plug-in module.
Prev Menu:
Press “Select” will bring the plug-in’s greeting message screen back.
