FRONT PANEL LCD DISPLAY
TranScend Chassis – Operation Manual 4-29
Attn(dB): Increasing or decreasing 0.5 dB per unit, by pressing “Left” or “Right” button. The full range is 0 - 31.5 dB.
Save: To select yes or no to save the change into NVRAM.
Status Menu:
Opt Pwr (dBm): Displays the optical input power reading in dBm.
Attn (dB): Displays the attenuation reading in dB.
Mode: Displays the mode setting in Setup menu.
Laser Tmp(C): Displays the laser temperature in Centigrade.
OPout Pwr(dBm): Displays the optical output power in dBm.
Alarm Menu:
OptPwr: Displays the alarm state of the optical input power.
Syn Lock: Displays the alarm state of synthesizer lock status.
OPout Power: Displays the alarm status of optical output power.
Laser Temp: Displays the alarm status of laser temperature.
Module Temp: Displays the alarm status of module temperature.
Chassis Menu:
Temp(C): Displays the module’s temperature reading in Centigrade.
Model: Displays the model name of plug-in module.
HW Ver: Displays the hardware version information of plug-in module.
SW Ver: Displays the software version information of plug-in module.
Ser #: Displays the serial number of plug-in module.
Prev Menu:
Press “Select” will bring the plug-in’s greeting message screen back.
