CRAFT LINE INTERFACE (CLI)
TranScend Chassis – Operation Manual 5-21
Example #1: In this example, the module in slot 1 reports its optical receiver power reading as -8.0 dBm on
channel 1.
Transcend [slot-1] >opticalPowerdbm 1
-8.0 (dBm)
GainReserve: Displays the gain reserve in dBm.
Example #1: In this example, the module in slot 1 reports its gain reserve as 6 dBm.
Transcend[slot-1] >GainReserve
6 (dBm)
Mode: Displays the gain control mode setting: MGC/AGC
Example #1: In this example, the module in slot 1 reports its gain control mode is MGC
Transcend [slot-1] >mode
MGC
ChannelMode: Displays the frequency channel plan mode.
Example #1: In this example, the module in slot 1 reports its frequency channel mode is 4-channel mode.
Transcend [slot-1] >channelmode
4
LaserTempAlarm: Displays the alarm status of laser temperature.
Example #1: In this example, the module in slot 1 reports the alarm status of laser temperature as “MajorLoLo”
(e.g. Major alarm with power reading below the low low threshold).
Transcend [slot-1] >LaserTempAlarm
MajorLoLo
OpticalPowerAlarm: Displays the alarm status of optical power.
Example #1: In this example, the module in slot 1 reports the alarm status of optical power as “MajorLoLo” (e.g.
Major alarm with power reading below the low low threshold).
Transcend [slot-1] >OpticalPowerAlarm
MajorLoLo
OPoutPowerAlarm: Displays the alarm status of optical output power.
Example #1: In this example, the module in slot 1 reports the alarm status of optical output power as
“MajorLoLo” (e.g. Major alarm with power reading below the low low threshold).
Transcend [slot-1] >OPoutPowerAlarm 1
MajorLoLo
