Continuation for All Vehicles:
– Remove the left and right bolt -2- from the engine mount.
– Disconnect the connector -1- for the Oxygen Sensor 1 After
Catalytic Converter - GX7- -2- and free up the wires. (There
are different installation positions.)
– Remove the connector -1- from the bracket and disconnect it.
– Remove the Oxygen Sensor 1 Before Catalytic Converter -
GX10- -2- using a tool from the -3337- .
– Remove the nuts -1- and the catalytic converter upward.
Audi A4 2015 ➤ , Audi A4 China 2016 ➤ , Audi A5 2016 ➤
4-Cylinder Direct Injection 2.0L 4V TFSI Engine (EA 888 Generation III) - Edition 11.2019
12 Rep. Gr.10 - Engine Assembly
