AudiR Infra-Red
Controller
Frequencies
Displays a list of the frequencies and channel numbers
available on the device being programmed, with the
current frequency highlighted, and allows you to change
the frequency:
• Tap the frequency you want to use, and tap Update to
update the transmitter or receiver.
Device
Displays device specific information about the product
being addressed:
Edit
Provides miscellaneous settings, depending on the
device:
User Notes: Allows you to enter a 16-character user ID,
which will be stored in the device for future reference.
Only numeric user IDs can be displayed using the
Switch
iR
User Id function.
AF Attenuation (receiver only): Allows you to adjust the
AF attenuation from 0dB to -32dB.
Mic Gain (transmitter only): Allows you to set the
microphone gain between 0 and 9, where each step
corresponds to approximately 3dB.
LF cut (transmitter only): Allows you to enable or disable
the low frequency cut.
