AudioCodes Mediant 500L MSBR

Hardware Installation Manual 14 Document #: LTRT-10453
Mediant 500L MSBR
3.2.1.2 Status LED
The Status LED indicates the operating status, as described in the table below.
Table 3-4: Status LED Description
LED
Color
LED
State
Description
Green On Device is operational.
Flashing
 Initial rebooting stage.
 Software upgrade (.cmp file) in process (currently supported
only in Software Version 6.8).
Red On Boot failure.
- Off Advanced rebooting stage.
3.2.1.3 Wi-Fi LED
The Wi-Fi LED indicates the Wi-Fi link status, as described in the table below.
Table 3-5: Wi-Fi LED Description
LED Color LED State Description
Green On Wi-Fi is activated.
Flashing Traffic on the wireless LAN.
- Off Wi-Fi is not configured.
3.2.1.4 WAN LEDs
This section describes the WAN LEDs.
3.2.1.4.1 WAN 4G LED
The WAN 4G LED indicates the status of the cellular WAN link (4G LTE or 3G), as
described in the table below.
Table 3-6: WAN 4G LED Description
LED
Color
LED
State
Description
Green On Connected to the cellular network.
Flashing In the process of connecting to the cellular network.
Red On No SIM card in the SIM slot, or if there is a SIM card, the device
cannot connect to the cellular network.
- Off Cellular WAN interface has not been configured (or the
functionality is not included in the device's installed License Key).
3.2.1.4.2 WAN GE LED
The WAN GE LED indicates the status of the Gigabit Ethernet (copper) WAN link, as
described in the table below.
