MSBR Series 47 MSBR Series
Hardware Installation Manual 6. Cabling the Device
6.6 Connecting a USB Storage Device
The device supports USB storage capabilities, using an external USB hard drive or flash
disk (disk on key) connected to the device's USB port. The storage capabilities are
configured through CLI and include the following:
Saving network captures to USB
Upgrading the device's firmware from USB
Updating the device's configuration from USB
Saving the current configuration to USB
To connect the USB storage device:
Connect the USB storage device to the USB port, located on the rear panel.
Figure 6-19: Connecting USB Storage Device
Note:
• Only a single USB storage (formatted to FAT/FAT32) operation is supported at any
given time.
• The USB port is not provided when the device is ordered with LTE cellular support.
