MSBR Series 37 MSBR Series
Hardware Installation Manual 6. Cabling the Device
6.2 Connecting LAN Interfaces
The device's Gigabit Ethernet LAN ports (1000Base-T) can be connected to network
equipment and entities such as computers, switches, and IP phones. These ports support
half- and full-duplex modes, auto-negotiation, and straight or crossover cable detection.
Cable specification:
Cable: straight-through Cat 5e or Cat 6 cable
Connector: RJ-45
Connector Pinouts:
Table 6-4: RJ-45 Connector Pinouts for GE
Pin Signal Name
1
Ethernet signal pair (1000Base-T)
2
3
Ethernet signal pair (1000Base-T)
6
4
Ethernet signal pair (1000Base-T)
5
7
Ethernet signal pair (1000Base-T)
8
Shield Chassis ground
