1 Introduction
This document provides a hardware description of the Mediant 500 MSBR (hereafter
referred to as device) and step-by-step procedures for mounting and cabling the device.
The device supports the following interfaces:
Multiple WAN, depending on ordered configuration:
• Single Gigabit Ethernet copper (10/100/1000Base-T) unshielded twisted pair
(UTP) interface port
• Dual-mode of 1.25 Gbps Optical Fiber Small Form-Factor Pluggable (SFP)
• ADSL2+ / VDSL2
• 3G/4G Cellular WAN access (primary or backup), using a USB modem
• 4G Cellular WAN access, using an integrated LTE modem
Four Gigabit Ethernet (1000Base-T) LAN ports (RJ-45).
One USB port for optional USB storage services and 3G cellular WAN modem.
Optional PSTN telephony interfaces:
• Up to four FXS port interfaces
• Up to four FXO port interfaces
• Up to four ISDN BRI port interfaces, supporting up to eight voice channels as well
as PSTN fallback
(Optional) Wireless LAN 802.11n/b/g (Wi-Fi) access point, providing two integrated,
multiple-input and multiple-output (MIMO) 2Tx/2Rx antennas that operate in the 2.4
GHz frequency range.
Serial console port (RJ-45) for device management
Note:
• Hardware configurations may change without notice. Currently available hardware
configurations are listed in AudioCodes Price Book. For further enquiries, please
contact your AudioCodes sales representative.
• The SFP module can be used for WAN fiber-optic interface or WAN copper interface.
• The USB port is not provided when the device is ordered with LTE cellular support.
• For information on configuring the device, refer to the device's User’s Manual.
