MSBR Series 17 MSBR Series
Hardware Installation Manual 3. Physical Description
Item # Label Description
4
USB 2.0 port, which can be used for the following:
3G cellular WAN modem for primary or backup WAN
External USB hard drive or flash disk (disk on key) for USB
storage capabilities (for example, for configuration file)
Note: The USB port is not provided when the device is ordered with
LTE cellular support.
5 //
Reset pinhole button for resetting the device or for restoring it to
factory defaults. To restore the device to factory defaults, do the
following:
With a paper clip or any other similar pointed object, press and hold
down the pinhole button for at least 12 seconds, but no longer
than 25 seconds
6 WAN WAN interface ports, which can be any of the following (depending
on ordered configuration):
GE: Copper GE
GE SFP: SFP module - dual-mode supporting 1.25 Gbps
V/ADSLoPOTS: ADSL/2+ and VDSL2
Note: For available WAN configurations, contact your AudioCodes
sales representative.
7 S1 (Slot 1)
GE LAN
Up to four Gigabit Ethernet (1000Base-T) ports (RJ-45) for
connecting to LAN network such as IP phones, computers, and
switches. These ports support half- and full-duplex modes, auto-
negotiation, and straight or crossover cable detection.
8
Wi-Fi pinhole button for enabling and disabling Wi-Fi. Use a paper
clip or any other similar pointed object to press the button.
Note: The Wi-Fi button is available only for models ordered with the
Wi-Fi functionality.
9 FXS / FXO / BRI Telephony interfaces, depending on ordered configuration:
Up to four ISDN BRI port interfaces (RJ-45)
Up to four FXS port interfaces (RJ-11)
Up to four FXO port interfaces (RJ-11)
10 - Cellular antennas for 4G LTE network.
Note: The antennas are applicable only to models ordered with the
4G LTE cellular functionality.
11
SIM card slot for 4G LTE cellular.
Note: The SIM card slot is applicable only to models ordered with
the 4G LTE cellular functionality.
12 - Multiple-input and multiple-output (MIMO) 2Tx/2Rx antennas,
operating in the 2.4 GHz frequency range for wireless LAN
802.11n/b/g (Wi-Fi) access point functionality.
Note: The antennas are applicable only to models ordered with the
Wi-Fi functionality.
